DEHNguard 40kA for 690V 1P overspenningsvern

Varenummer: D952938
Lagerbeholdning:

Uc: 1000V. Med meldekontakt

Uc: 1000V. Med meldekontakt

Pluggbar 1-polet overspenningsvern for Un: 690V. Uc: 1000V. Med meldekontakt.

Bruk laskeskinne hvis du skal koble flere sammen:



  • Universal surge arrester comprising a base part and a plug-in protection module
  • Prewired single-pole surge arrester with clear "Lifetime Indication“
  • Two-step (green-red) linked with remote signalling contact
  • High discharge capacity Imax up to 40 kA (8/20 μs)
  • Prompts the user in time to replace the protection module in case of imminent arrester overload; early warning system
  • The arrester is fully operational until the protection module is replaced and is thus suited for use in condition monitoring systems
  • Energy coordination with other arresters of the Red/Line product family
  • Easy replacement of protection modules without tools due to module locking system with module release button

DEHN jordingsskinne for 1.5 moduls single fase 3P

med terminal opp til 25 mm²
D900418

DEHN jordingsskinne for 1.5 moduls single fase 4P

med terminal opp til 25 mm²
D900429
